Tarot 450PRO V2 Flybarless 3 Axis Gyro Super Combo / Silver	Login for price
Price Unavailable

Tarot 450PRO V2 Flybarless 3 Axis Gyro Super Combo / Silver

larger image

Model: FYTL20006B-SC
Shipping Weight: 1413 grams
Manufactured by: Tarot


Newly improved low wind resistance specialized flybarless rotor head assembly	High precision bearing mixing arms	Integrated battery / ESC mount, allowing adjustment based on battery dimension for optimal CG of the helicopter

Newly designed gyro mount	Newly designed main frame set to simplify servos installation and maintenance	Highly rigid frame with single piece carbon side and bottom plates/1.2mm

Highly rigid frame with single piece carbon side and bottom plates/1.2mm	Vertical rudder servo mount design moving the CG closer to center	Unique opposing weighted tail blade grips effectively increase rudder and gyro performance

Single piece integrated landing gear	Fiberglass painted canopy	Flybar-less rotor hub

Newly improved low wind resistance specialized flybarless rotor head assembly, with reduced distance between rotor head and frame, effectively lowering the CG for better 3D performance.
Improved side frame design, with dedicated 3GX mounting location. 3GX can be placed in between frames, or behind anti-rotation guide, resulting in clean wire management and improved aesthetics.
Unibody main shaft and servo mount, with modified side frame connecting points, simplifying servo replacement and improving ease of maintenance.
Brand new MX series high efficiency brushless motor, with heat sink style casing and built in cooling fan, effectively increase heat dissipation during operation, improving power output.
Integrated battery / ESC mount, allowing adjustment based on battery dimension for optimal CG of the helicopter. Additionally the number of screws has been reduced to minimize assembly and maintenance time.
High efficiency tail shaft drive design, dramatically reduce power loss associated with belt driven system, and at the same time increase power output.
Vertical rudder servo mount design moving the CG closer to center, improving agility during 3D maneuvers.
Unique opposing weighted tail blade grips effectively increase rudder and gyro performance, for superior tail locking and higher precision.
Users must have a certain concept of security to operate the R/C helicopters.
Be sure to read and comply with related safety notes of instruction manual before flying.

TAROT 3 Axis Gyro System ZYX S Version
The ZYX-S and ZYX 3.0's new function:
-The ZYX-S add DSM2 and DSMJ satellite receiver support function.
-TheZYX-S add Futaba S-Bus receiver support function.
-The ZYX-S add failsafe function when using DSM2 and DSMJ satellite receiver,
user can set the failsafe values for throttle and collective pitch.
-The ZYX-S add four aircraft configrations: '+' quadrotor, 'X' quadrotor,
conventional airplane(enhance hover and 3D flight), delta airplane.
-The ZYX-S can use the USB adapter to connect to PC, the new PC software is
ZYX 3.0. It can be setup by the ZYX multifunctional gyro programmer.
Instruction: The TAROT ZYX high performance multi-function 3-axis gyro system is the lightest flybarless system in the world. It is compatible with all 200-700 nitro or electric power helicopters and support 90, 120, 135, and 140 degree CCPM swashplate systems. Furthermore, it is compatible with all type servos, and support firmware update. The setup process is quite easy, needs only ten minutes.
ZYX 3-axis gyro system provides two different flight modes, which can satisfy players from beginners to advanced. ZYX 3-axis gyro system has many adjust options; pilots can adjust the parameter of swash plate and rudder servo, which make pilots feel the impressive of the flybarless helicopter.
ZYX high performance 3-axis gyro system uses MEMS gyro sensor which can be used in bad weather condition and pilots can control the flying status of helicopter precisely. Built-in pirouette flip optimization function, the speed of pirouette is really stable. When the helicopter pirouettes flip, the fuselage will spin at one point without shifting.
Specification:
1) Dimensions: 37.2mm*25.2mm*13mm
2) Weight: 9.8g (not including connecting wire and adaptor)
3) Operating voltage: DC 3.5V-9V
4) Operating current drain: 60mA
5) Operating temperature:-15C~65C
6) Maximal angular velocity: 800 degrees/sec
7) Tail servo compatibility: 1.52ms analog servo, 1.52ms digital servo, 760us digital servo, 960us digital servo
8) Swashplate servo compatibility: 1.52ms analog servo, 1.52ms digital servo
9) Radio compatibility: PPM, PCM, 2.4G
10) Supporting firmware upgrade
11) Supporting Multi-Blade Rotor Head

Length: 635mm
Height: 230mm
Main Rotor Diameter: 710mm
Tail Rotor Diameter: 158mm
Motor Drive Gear: 15T
Main Drive Gear: 150T
Autorotation Tail Drive Gear: 106T
Tail Drive Gear: 25T
Drive Gear Ratio: 1:10:4.24
Weight(w/o power system): 530g

Flying Weight: Approx. 640g

Tarot 450 PRO EFL Carbon Fiber Kit Set Black Color x 1 set
Carbon blades x 1set
Thread locker X 1
Main Blade Sponge Holder X 1
HolderBattery Reclosable Fastener X1
TarotPentium-40A ESC TL2345
Tarot ZYX-S 3 Axis Gyro FYTLZYX08
450 PRO Brushless Motor 3800KV/3.5MM TL450M
450 T9257 Digital Gyro Servo 1520US TL2301
MD993 Metal Gear Digital servo
